General | Vehicle Name | 1SUZU FTR 10T Palfinger Crane Truck |
Chassis Brand | 1SUZU FTR | |
Overall Dimension(mm) | 9000×2510×3850 | |
GVW(kg) | 18000 | |
Curb Weight(KG) | 10550 | |
Cab | Cab Seat | 3 |
Air Conditioner | Yes | |
Engine | Fuel Type | Diesel |
Engie Model | 6HK1-TCL | |
Engine Brand | 1SUZU | |
Power(KW) | 205HP | |
Emmission Standard | Euro 2,3,4,5,6 | |
Chassis | Drive Type | 4X2 |
Transmission | 6-speed gearbox, Manual | |
Wheelbase(mm) | 5800 | |
Tyre Specification | 11.00R20 | |
Tyre No.(pcs) | 6+1 | |
Max Speed(km/h) | 85 | |
Paint | as your required | |
Superstructure | Crane | 10T 5-section straight boom crane |
Max lifting height | 16.3m | |
Max working radius | 14.3m | |
Rotation Angle | 360° | |
Box material | Bottom 4 sides 3 | |
Crane type | Straight Telescopic or folding arm | |
box size | 5700x2300x600mm | |
Optional function | 1. Knuckle boom crane. 2. Hydraulic tipper box. 3. Box thickness according to requirement.4. Box height could be nominated 5. Brick clamping apparatus 6. Remote control operation 7. Grab bucket 8. Aerial work basket 9. Drill 10.Double row cab |
